S9-988D series Direct-drive Servo Motor
Application:
Apply to all kinds of JUKI overlock sewing machine MO6700/6800/6900/3300 series;
YAMATO overlock sewing machine AZ6100/AZ8000 series;
PEGASUS overlock sewing machine EX/MX/M700/800/900/600/LX series;
SIRUBA overlock sewing machine 747K/747F/747E/988 series;
KINGTEX overlock sewing machine 9000/7000 series;
BROTHER overlock sewing machine 520 series;
Main Feature:
1. Integrated circuit board design for more reliable internal connections.
2.Integrative structure, equipped with bobbin winder( If you need the bobbin winder, you need to pay separately). Easier installation and more reliable performance.
3.Powered by high performance direct-drive servo motor. Powerful torque, low noise, more stable quality and more energy efficient.
4.The control box design has a block protection function, which is greatly reduces the motor coil fault.
5. Adopt large capacitors to ensure long life of control box.
6.100% power requests motor copper rotation.
7.The PCB special design for power fluctuation, frequently power off and on, with short but very higher voltage district power by generator.
8. It is also ok for the old above mentioned styles sewing machine.
9. The control box has the below function: Speed adjustment, Needle position up and down, 12V LED output and 220V output.
Direct drive motor installation diagram:
